High quality DN50 standard orifice oil liquid flow meter

FOB Reference Price:Get Latest Price
US $300-500 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Henan, China (Mainland)
Brand Name:
AFT
Model Number:
LGB
Product Name:
Compact orifice plate oil flow meter
Name:
Orifice plate
Connection:
Flange
Medium:
Liquid,Oil
Accuracy:
0.5~1.5
Application:
Measuring Liquids,gas
Pressure:
≤40
Material:
carbon steel, stainless steel
Repeatability:
0.1%
Caliber:
DN50-DN1000
Supply Ability
Supply Ability:
5000 Set/Sets per Year High quality DN50 standard orifice oil liquid flow meter
Packaging & Delivery
Packaging Details
High quality DN50 standard orifice oil liquid flow meter : Each of our meter after factory calibration, according to different size do packaging, usually, below 100 mm flow meter will be used in fine carton packaging, above 100 mm flow meter will be used free of steam box packaging. We will ensure that each flow meter, safe to reach your hands
Port
Qingdao/Shanghai/Tianjin/Dalian
Lead Time :
Quantity(Sets) 1 - 3 >3
Est. Time(day) 5 To be negotiated

High quality DN50 standard orifice oil liquid flow meter

 Electromagnetic Flow (1)

Why Choose us?

  1. Time is gold ”for you and for us, we have professional team work who can make nice quality in short time.
  2. With us your money in safe your business in safe ”full refund in case of bad quality or delay delivery time , we also accept payment by paypal.

  3. We are the leader manufacturer of flow meter in china.
  4. Alibaba Assessed Gold Supplier.
  5. Inspected by the Inspection Institution of Bureau Veritas Certification.
  6. 100% QC inspection Before Shipping.
  7. Exports to many countries.High quality DN50 standard orifice oil liquid flow meter.png

    Introduction of orifice plate flowmeter

    Standard orifice plate is one product of the throttle device which has simple structure ,installation convenient and has the most adaptable,its design manufacture and use are suitable for international standard ISO 5167 or GB/T rules.



    orifice plate flowmeter display

High quality DN50 standard orifice oil liquid flow meter.png



Feature  of orifice plate flowmeter



1. Simple structure ,strong,convenient installation.

2. Can measured all kinds of flow of gas ,steam and liquid ,and wide usage.

3. Don’t need real flow calibration ,with moderate precision.

4. Attachment is complete ,it can design and calculation for the user.

5. It be can equipped with Intelligent differential pressure transmitter, and realize temperature ,pressure compensation or the scene concentric line communicating mode.





Taking pressure mode: Corner joint (Riting chamber or drill alone )taking pressure, Flange taking  pressure, D-D/2 taking pressure

  • Nominal pressure: ≤40Mpa,(when ≥20Mpa ,it can use high pressure lens orifice plate or welding type)
  • Caliber: 50~1000mm(standard orifice plate) or<50mm(ensemble plate)>1000mm(plate orifice-plate)
  • Accuracy(Inderterminacy): ±0.5% ~ ±1.5%
  • Range of application:  open hole diameter(mm):d ≥12.5(standard orifice plate)

                                      open hole diameter rate β :0.1 ≤β≤0.75

                                      Reynolds number range ReD: 0.1 ≤β≤0.75

                                      107 ≥ReD≥5000 and ReD≥10β2D:D can be use (mm)show



We have a professional sales team, we can choose the most suit yours orifice plate flowmeter



High quality DN50 standard orifice oil liquid flow meter.png

High quality DN50 standard orifice oil liquid flow meter.png

Purchase our orifice plate flowmeter customers:

High quality DN50 standard orifice oil liquid flow meter 33.png

High quality DN50 standard orifice oil liquid flow meter222.png
